100-240VAC 0-10V Dimmer
100-240VAC 0-10V Dimmer PA-112U
Feature
1. Wide input voltage of 100-240VAC
2. Single channel，output 0-10V analog dimming signal
3. Can achieve 255 levels brightness adjustment
4. High sensitive & high stable touch panel, fast & precise control
5. Interface using tempered glass material, stylish appearance
Technical Parameter
| Item | PA-112U | |
|
Input |
Voltage | 100-240VAC |
| Frequency | 50/60Hz | |
| Static power | ＜1W | |
|
Output |
Channel | 1 |
| Voltage | 100-240VAC | |
| Frequency | 50/60Hz | |
| Analog signal | 0-10V | |
| Maximum signal current | ＜15mA | |
| Power | ＜200W | |
|
Others |
Dimension | 74*120*41.8mm（L*W*H） |
| Packing size | 145*99*53mm（L*W*H） | |
| N.W. | 184g | |
| G.W. | 241g | |
| Operating temperature | -20℃ - 60℃ | |
