180-360W 15A*1ch 12-24VDC Triac Dimmer DIM105

Short Description:

  • Item No.: DIM105
  • Output Power: 180-360w
  • Dim Mode: Triac/ELV

Product Detail

Product Tags

180-360W 15A*1ch 12-24VDC Triac Dimmer DIM105


Welcome to use our company’s DIM105 Triac dimmer, this dimmer is a constant voltage dimmer, output current is 15A max. Adopt the advanced microcomputer control technology, and use the advanced electronic components. This dimmer has stable performance and high quality. It’s can be used widely at building, hotel, KTV and home.

1. Triac dimming, input dimming signal:AC40V~220V
2. Support all the triac dimming system, such as Lutron, Clipsal,Dynalite
3. Single channel output, output current 15A max
4. The dimming curve smooth, no flicker
5. 0-100% brightness control
6. Has over current protection, short protection, over temperature protection
7. Has Power LED to indicate current status:
Power LED Off: Work normally
Power LED ON: Connection error or over current & short protection & over temperature

Technical Parameter

Product Name 12V 24V 15A Triac Constant Voltage LED Dimmer
Item DIM105
Input Voltage DC12-24V
Dimming Voltage AC40-220V
Output Current 15A max
Output Power 12V:180W max; 24V:360W max
Work Temp. -20 – 50℃
Product Size 167(L)×52(W)×24(H) mm
Packaging Size 175(L)×57(W)×30(H) mm
N.W. 83.5g
G.W. 114g
