180-360W 15A*1ch 12-24VDC Triac Master Controller DIM105L

Short Description:

  • Item No.: DIM105L
  • Input Voltage: 12-24
  • Output Current: 15A*1
  • Output Voltage: 12-24
  • Output Power: 180-360
  • Dim Mode: ELV
  • G.W.: 115
  • Size: 167*52*24

Product Detail

Product Tags

180-360W 15A*1ch 12-24VDC Triac Master Controller DIM105L


Welcome to use our company’s DIM105 Triac dimmer, this dimmer is a constant voltage dimmer, output current is 15A max. Adopt the advanced microcomputer control technology, and use the advanced electronic components. This dimmer has stable performance and high quality. It’s can be used widely at building, hotel, KTV and home.

1. Triac dimming, input dimming signal:AC40V~110 V
2. Support all the triac dimming system, such as Lutron,Clipsal,Dynalite
3. Single channel output, output current 15A max
4. The dimming curve smooth, no flicker
5. 0-100% brightness control
6. Has over current and short protection, safety to use
7. Has Power LED to indicate current status:Power LED ON: Work normally;Power LED Off: Connection error or over current & short protect;
8. Has adjustable resistor to adjust dimming curve,keep the consistency of the different dimmers.
Installation Notes
1.Input voltage must be fit the production work voltage
2.Do not overload
3 .Before commissioning of the power,
4.If failure, do not privately maintenance, please contact the supplier should ensure that all wiring is correct before electricity.

Technical Parameter


Product Name Triac Constant Voltage Dimmer
Item DIM105L
Input Voltage DC 12-24V
Dimming Voltage AC 40-110V
Output Current 15A max
Output Power 12V:180W max 24V:360W max
Work Temp. -20 – 50℃
Product Size 167(L)×52(W)×24(H) mm
Packaging Size 175(L)×57(W)×30(H) mm
N.W. 83.5g
G.W. 114g
