| Input |
Efficiency |
≥83%@100VAC, ≥85%@230VAC, full load |
| Voltage |
100VAC-240VAC |
| Frequency Range(Hz) |
50/60Hz |
| AC Current(max) |
0.38Amax@100VAC, 0.17Amax@230VAC |
| PF |
≥0.95@100VAC, ≥0.90@230VAC, full load |
| THD |
<10%@100VAC, <15%@230VAC, full load |
| Inrush Current(max) |
Cold start, 11.1A@100VAC 68us, 21.1A@230VAC 76us |
| Standby power |
<0.5W@100VAC |
| No load power |
<1W@100VAC |
| Turn on delay Time |
<0.75s @127Vac (reaches 90% brightness) |
| Output |
Current |
550mA |
600mA |
650mA |
700mA |
750mA |
800mA |
850mA |
900mA |
| Voltage |
9-45VDC |
9-45VDC |
9-45VDC |
9-42VDC |
9-40VDC |
9-37VDC |
9-35VDC |
9-33VDC |
| Power |
24.75W |
27W |
29.25W |
29.4W |
30W |
29.6W |
29.75W |
29.7W |
| Current Tolerance |
±5% |
|
|
| Channel |
1 |
| Pst LM |
≤1.0 |
| SVM |
≤0.4 |
| Load Regulation |
±5% |
| Line Regulation |
±3% |
| Function |
Dimming Type |
DALI2.0, PUSH DIM |
| Dimming Range |
0.3%-100% |
| Dimming curve |
Logarithm |
| Flicker |
Flicker free |
| Protection |
Short Circuit |
Hiccup Protection, Auto-recovery after Fault Clearance |
| Overload |
Current decrease, Auto-recovery after Fault Clearance |
| Safety&EMC |
Surge |
L-N: 1kV |
| Withstand Voltage |
I/P-O/P: 3000VAC/1min/<5mA I/P-Signal:1500VAC/1min/<5mA O/P-Signal: 3000VAC/1min/<5mA |
| Safety standards |
CCC (China) GB/T 19510.1，GB/T 19510.213 TUV (Germany)EN 61347-1，EN 61347-2-13，EN 62493 |
| CB (CB member states)IEC61347-1，IEC61347-2-13 CE (European Union)EN 61347-1，EN 61347-2-13 |
| RCM (Australia) AS/NZS 61347-1, AS/NZS 61347-2-13 ENEC (Europe)EN 62384 |
| EMI Emission |
CCC (China) GB/T 17743，GB/T 17625.1 |
| CE (European Union) EN 55015，EN 61000-3-2，EN 61000-3-3，EN 61547 |
| RCM (Australia) AS/NZS CISPR 15，AS/NZS 61000 |
| EMC Immunity |
IEC 61000-4-2, 3, 4, 5, 6, 8, 11; EN61547 |
| Insulation Resistance |
5MΩ |
