0-10V/1-10V Dimming LED driver, 0-10V/1-10V Dimming LED controller, 0-10V/1-10V Dimming LED dimmer - Euchips

96W 24VDC DALI&0/1-10V CV Driver MUP96AD-1W24V-BW

96W 24VDC DALI&0/1-10V CV Driver MUP96AD-1W24V-BW Features · Single channel constant voltage output, Output Current 4A Max · Input Voltage Range 108-305Vac · Support 0/1-10V ,Potentiometer,PWM,DALI Dimming · Dimming range of 0.1-100%, and dimming effect smooth, flicker free · 100% output when no dimming signal input, can be used as normal power supply · Protection: Overload; short circuit; Overcurrent · Class 2 Output · Safety according to UL8750 &UL 1310 · Suitable for Dry , Damp &am...

detail
96W 24VDC DALI&0/1-10V CV Driver MUP96AD-1W24V-B

96W 24VDC DALI&0/1-10V CV Driver MUP96AD-1W24V-B MUP96AD-1W24V-B is a constant voltage mode output LED driver. This driver complies with DALI standard protocol IEC 62386, and provides DALI,0/1-10V active signal dimming. Features · Single channel constant voltage output,4A Max · Wide input voltage of 120VAC ~ 277VAC · Dimming range of 0.1-100%, and dimming effect smooth, Flicker free · 100% output when no dimming signal input, can be used as normal power supply · Protection: Over load; s...

detail
280W 24VDC 3ch DALI&0/1-10V CV Driver MUP288ADS-3W24V-B

280W 24VDC 3ch DALI&0/1-10VDALI&0/1-10V CV Driver MUP288ADS-3W24V-B MUP288ADS-3W24V-B is a constant voltage mode output LED driver. This driver complies with DALI standard protocol IEC 62386, and provides DALI,0/1-10V active signal dimming. Features · Single channel constant voltage output,4A Max · Wide input voltage of 120VAC ~ 277VAC · Dimming range of 0.1-100%, and dimming effect smooth, Flicker free · 100% output when no dimming signal input, can be used as normal power supply · I...

detail
192W 24VDC 2ch DALI&0/1-10V CV Driver MUP192ADS-2W24V-B

192W 24VDC 2ch DALI&0/1-10V CV Driver MUP192ADS-2W24V-B MUP192ADS-2W24V-B is a constant voltage mode output LED driver. This driver complies with DALI standard protocol IEC 62386, and provides DALI,0/1-10V active signal dimming. Features · Dual channel constant voltage output, the maximum output current per channel is 4A · Wide input voltage of 120VAC ~ 277VAC · Dimming range of 0.1-100%, and dimming effect smooth, Flicker free · 100% output when no dimming signal input, can be used as no...

detail
60W 12VDC 0/1-10V CV Driver MUP60A-1W12V

60W 12VDC 0/1-10V CV Driver MUP60A-1W12V MUP60A-1W12V is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features ·Single channel constant voltage output,5.0A Max ·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal) ·High input voltage of 120VAC ~ 277VAC ·Dimming range of 1-100%, and dimming effect smooth, no flick...

detail
10W 120~350mA 0/1-10V CC Driver PUP10A-1WMC-350

10W 120~350mA 0/1-10V Constant Current Driver PUP10A-1WMC-350 PUP10A-1WMC-350 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 100VAC ~ 240VAC 4...

detail
60W 24VDC 0/1-10V CV Driver MUP60A-1W24V

60W 24VDC 0/1-10V CC Driver MUP60A-1W24V MUP60A-1W24V is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features ·Single channel constant voltage output,2.5A Max ·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal) ·High input voltage of 120VAC~277VAC ·Dimming range of 1-100%, and dimming effect smooth, no flicker...

detail
150W 24VDC DALI&0/1-10V CV Driver LCPN150AD-1H24V

150W 24VDC DALI&0/1-10V CV Driver LCPN150AD-1H24V Features · Single channel constant voltage output, maximum output current 6.25A · Short circuit, overload protection, V0 flame retardant housing · Dimming range 0.1%-100% dimming, smooth dimming without step sense and Flicker free · Life of 50,000 hours, 5 years warranty · Customizable dimming curve · Long strip shape design, easy to install in narrow space · Built-in PFC chip to improve energy efficiency and reduce pollution Technical Par...

detail
10W 350~700mA 0/1-10V CC Driver PUP10A-1WMC-700

10W 350~700mA 0/1-10V Constant Current Driver PUP10A-1WMC-700 PUP10A-1WMC-700 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 100VAC ~ 240VAC 4...

detail
96W 12VDC 0/1-10V CV Driver MUP96A-1W12V

96W 12VDC 0/1-10V CC Driver MUP96A-1W12V MUP96A-1W12V is a constant voltage mode output LED driver.This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features ·Single channel constant voltage output,8.0A Max ·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal) ·High input voltage of 120VAC~277VAC ·Dimming range of 1-100%, and dimming effect smooth, no flicker ·...

detail
20W 350~700mA 0/1-10V CC Driver PUP20A-1WMC

20W 350~700mA 0/1-10V Constant Current Driver PUP20A-1WMC PUP20A-1WMC is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 100VAC ~ 240VAC 4. Dimmin...

detail
96W 24VDC 0/1-10V CV Driver MUP96A-1W24V

96W 24VDC 0/1-10V CV Driver MUP96A-1W24V MUP96A-1W24V is a constant voltage mode output LED driver.This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features ·Single channel constant voltage output,4.0A Max ·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal) ·High input voltage of 120VAC~277VAC ·Dimming range of 1-100%, and dimming effect smooth, no flicker ·...

detail
