DALI Series

Dimming Signal
CC/CV
Input Voltage
Output Voltage
Output Current
Output Power
Output Channel
Application Area
Product Category
Certification
Download CSV Display as Poster
  • 40W 12VDC DALI CV Driver EUP40D-1W12V-0

    40W 12VDC DALI CV Driver EUP40D-1W12V-0

    40W 12VDC 3.4A*1ch 100-240VAC Constant Voltage DALI Driver EUP40D-1W12V-0 Feature 1. Single-channel constant voltage output,12V; 2. Meet DALI Protocol IEC 62386 3. Support Touch-DIM function 4. Wide input voltage of 100VAC ~ 240VAC 5. High efficiency up to 86% 6. 100% output when no dimming signal input, can be used as normal power supply 7. Dimming effect smooth, no flicker 8. Over power protection , over voltage protection 9. Suitable for indoor LED lighting application Technical Parameter ...
  • 40W 24VDC DALI CV Driver EUP40D-1H24V-0

    40W 24VDC DALI CV Driver EUP40D-1H24V-0

    40W 24VDC DALI Constant Voltage LED Driver EUP40D-1H24V-0 Feature 1. Single channel constant voltage output 2. Support a variety of dimming mode(DALI/Touch DIM) ·High range of input voltage 220VAC ~ 240VAC 3. Built-in active PFC function ·Dimming effect smooth, no flicker 4. Over load protection; Short circuit protection; Over temperature protection 5. Suitable for indoor LED lighting application, such as LED Dimension (mm) strips, spot light,wall washer,and so on Technical Parameter  ...
  • 40W 350~1050mA*1ch DALI CC Driver PCP40D-1WMC

    40W 350~1050mA*1ch DALI CC Driver PCP40D-1WMC

    40W 350~1050mA*1ch DALI CC Driver PCP40D-1WMC PCP40D-1WMC is a constant current output mode LED driver. Support DALI dimming function, Touch DIM (Push DIM) function. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features · Single channel output, output current level selectable by DIP S.W. · Support DALI dimming function, Touch DIM (Push DIM) function · Dimming range: 1-100%...
  • 75W 12VDC DALI CV Driver EUP75D-1H12V-0

    75W 12VDC DALI CV Driver EUP75D-1H12V-0

    75W 12VDC 6.2A*1ch 220-240VAC Constant Voltage DALI Driver EUP75D-1H12V-0 Features 1. Single channel constant voltage output, 6.2A max. 2. Meet DALI Protocol IEC62386 3. Support Touch DIM function 4. Wide input voltage of 220‐240VAC 5. Dimming effect smooth, no flicker 6. Over load protection; over voltage protection; short circuit protection; over temperature 7. IP20, Suitable for indoor LED lighting application Technical Parameter   Model EUP75D-1H12V-0 Output Channels 1 Voltage...
  • 75W 24VDC DALI CV Driver EUP75D-1H24V-0

    75W 24VDC DALI CV Driver EUP75D-1H24V-0

    75W 24VDC DALI Constant Voltage Dimmable Driver EUP75D-1H24V-0 Feature 1. Single channel constant voltage, 3.1A Max 2. Meet DALI Protocol IEC62386 3. Support Touch DIM function 4. High input voltage of 220VAC ~ 240VAC 5. Over load protection; over voltage protection; short circuit; over temperature 6. IP20, suitable for indoor LED lighting application Technical Parameter   Product Name 75W 24VDC DALI Constant Voltage Dimmable Driver Model EUP75D-1H24V-0 Output DC Voltage 24VDC ...
  • 135W 12VDC DALI CV Driver EUP135D-1W12V-0

    135W 12VDC DALI CV Driver EUP135D-1W12V-0

    135W 12VDC 11.25A*1ch 100-240VAC Constant Voltage DALI Driver EUP135D-1W12V-0 Feature 1. Single channel constant voltage, 12VDC output. 2. Meet DALI Protocol IEC62386 3. Wide range of input voltage 100VAC ~ 240VAC 4. Support Touch-DIM func on 5. High efficiency up to 92% 6. Built-in PFC function 7. Protections: Short circuit, Over current. 8. IP 20 design 9. Suitable for indoor LED lighting application Technical Parameter Product Name 135W 12VDC DALI Constant Voltage Dimmable LED Driver ...
  • 150W 24VDC DALI CV Driver EUP150D-1W24V-0

    150W 24VDC DALI CV Driver EUP150D-1W24V-0

    150W 24VDC 6.25A*1ch Constant Voltage DALI Driver EUP150D-1W24V-0 Feature 1. Signal channel constant voltage, 24VDC output 2. Meet DALI Protocol IEC62386 3. Wide range of input voltage 100VAC ~ 240VAC 4. Support Touch-DIM function 5. High efficiency up to 92% 6. Built-in active PFC function 7. Protections: Short circuit, Over current 8. IP 20 design 9. Suitable for indoor LED lighting application Technical Parameter   Model EUP150D-1W24V-0 Output DC Voltage DC 24V Current 6.25A Ma...
  • 75W 24VDC 2ch DALI CV Driver DT8 EULP75D-2H24V

    75W 24VDC 2ch DALI CV Driver DT8 EULP75D-2H24V

    75W 24VDC 3.125A*2ch CV DALI Driver EULP75D-2H24V EULP75D-2H24V is a constant voltage mode output LED driver. It supports DALI standard protocol and adjustment of brightness and colour temperature. Features · 2 channels of constant voltage output, each carrying 3.125A ; separately ; When carrying multiple loads, the cumulative load shall not exceed 3.125A · Meet DALI protocol IEC 62386 DT8 · Dimming effect smooth, no flicker · Over load protection; short circuit protection · IP20, suitable fo...
  • 150W 24VDC 2ch DALI CV Driver DT8 EULP150D-2H24V

    150W 24VDC 2ch DALI CV Driver DT8 EULP150D-2H24V

    150W 24VDC 2ch DALI CV Driver DT8 EULP150D-2H24V EULP150D-2H24V is a constant voltage mode output LED driver. It supports DALI standard protocol and adjustment of brightness and colour temperature. Features · 2 channels of constant voltage output, each carrying 6.25A ; separately ; When carrying multiple loads, the cumulative load shall not exceed 6.25A · Meet DALI protocol IEC 62386 DT8 · Dimming effect smooth, no flicker · Over load protection; short circuit protection · IP20, suitable for ...
  • 75W 12VDC 2ch DALI CV Driver DT8 LCP75D-2W12V

    75W 12VDC 2ch DALI CV Driver DT8 LCP75D-2W12V

    75W 12VDC 6.25A*2ch Constant Voltage DALI Driver LCP75D-2W12V LCP75D-2W12V is a constant voltage mode output LED driver. It supports DALI standard protocol and adjustment of brightness and colour temperature. Feature 1. 2 channels of constant voltage output, each carrying 6.25A ; separately ; When carrying multiple loads, the cumulative load shall not exceed 6.25A 2. Meet DALI Protocol IEC62386 DT8 3. High input voltage of 120VAC ~ 277VAC 4. Dimming effect smooth, no flicker 5. Over load prot...
  • 75W 24VDC 2ch DALI CV Driver DT8 LCP75D-2W24V

    75W 24VDC 2ch DALI CV Driver DT8 LCP75D-2W24V

    75W 24VDC 3.125A*2ch Constant Voltage DALI Driver LCP75D-2W24V LCP75D-2W24V is a constant voltage mode output LED driver. It supports DALI standard protocol and adjustment of brightness and colour temperature. Feature 1. 2 channels of constant voltage output, each carrying 3.125A ; separately ; When carrying multiple loads, the cumulative load shall not exceed 3.125A 2. Meet DALI Protocol IEC62386 DT8 3. High input voltage of 120VAC ~ 277VAC 4. Dimming effect smooth, no flicker 5. Over load p...
  • 75W 12VDC 4ch DALI CV Driver LCP75D-4W12V

    75W 12VDC 4ch DALI CV Driver LCP75D-4W12V

    75W 12VDC 6.25A*4ch Constant Voltage DALI Driver LCP75D-4W12V LCP75D-4W12V is a constant voltage mode output LED driver and complies with DALI standard protocol IEC 62386 Feature 1. Single channel constant voltage output,6.25A Max 2. Meet DALI Protocol IEC62386 3. High input voltage of 120VAC ~ 277VAC 4. Dimming effect smooth, no flicker 5. Over load protection; over voltage protection; short circuit protection 6. IP20, suitable for indoor LED lighting application Technical Parameter Mode...
