320W 24VDC 2ch DALI CV Driver LCP320D-2H24V
320W 24VDC 2ch DALI CV Driver LCP320D-2H24V
LCP320D-2H24V is a constant voltage mode output LED driver. It supports DALI standard protocol and adjustment of brightness and colour temperature.
Features
· 2 channels of constant voltage output, each carrying 13.3A ; separately ; When carrying multiple
loads, the cumulative load shall not exceed 13.3A
· Meet DALI protocol IEC 62386 DT8
· Wide input voltage of 220VAC ~ 240VAC
· Dimming effect smooth, no flicker
· Over load protection; short circuit protection
· IP20, suitable for indoor LED lighting application
Technical Parameters
|
Model |
LCP320D-2H24V | |
|
Input |
Efficiency | ≥92%@230VAC, Full load |
| Voltage | 220VAC-240VAC | |
| Frequency Range(Hz) | 50/60Hz | |
| Power Factor | 0.95@230VAC, Full load | |
| AC Current(max) | 1.6Amax@230VAC | |
| Standby power | ≤2W | |
| Inrush Current(max) | Cold start,80A@230VAC | |
|
Output |
Current / Voltage / Power | 13.3A / 24VDC / 320W |
| Channel | 2 | |
| Ripple Voitage | 3% | |
| Turn on delay Time | ≤ 0.8 s, at230Vac (When the light begins to shine) | |
| No load output voltage | 25.2VDC max | |
|
Function |
Dimming Type | DALI Dimming |
| Dimming Range | 0.5%-100% Dimming to off | |
| Dimming curves | Logarithm | |
| Color temperature | 2700K-6500K | |
| Protection | Short circuit | Short circuit No output, troubleshooting output normal |
| Over load | If no output is displayed, the troubleshooting output is normal | |
|
Safety& EMC |
Surge | L-N:1KV |
| Withstand Voltage | I/P-O/P: 3000VAC/1min/5mA O/P-DIM( Signal port ): 1500Vac/1min/<5mA | |
| Safety standards | IEC/EN62384, IEC/EN61347-1, IEC/EN61347-2-13 | |
|
Others |
Working Temp. | -20℃~50℃ |
| Storage Temp., Humidity | -40℃~85℃, 20-90%RH | |
| tc | 90℃ | |
| Material | PC | |
| IP Rating | IP20 | |
| Lifetime | 50,000h@tc:75℃ | |
| Warranty Condition | 5 years | |
| Switch Cycle | 25,000 times | |
| Packing(weight) | Net weight:630g±5%/PCS; 25PCS/Carton;16.25kg±5%/Carton; Carton Size:377*241*196mm(L*W*H) | |
| Dimension | 360*40*32mm(L*W*H) |
