| Input |
Rated Voltage Range |
220VAC-240VAC |
| Rated Voltage |
198VAC-264VAC |
| Frequency Range(Hz) |
50/60Hz |
| Input Current |
0.75Amax@198VAC, 0.60Amax@230VAC, 0.5Amax@264VAC |
| Power Factor |
0.96@220-240VAC, Full load; 90%@220-240VAC, half load. |
| Efficiency |
92%@230VAC, Full load; 91%@230VAC, half load. |
| THD(full load) |
<10%@230VAC, Full load; <15%@230VAC, half load. |
| Leakage current |
≤0.7mA/240V |
| No load power |
<0.5W |
| Inrush Current |
Cold start 62A@230VAC 2.5us, |
| Output |
Output Voltage |
24VDC |
| Output Voltage Tolerance |
±3% |
| Output Current |
5A |
| Output Power Range |
120W |
| Strobe (depth of fluctuation) |
IEC-Pst≤1，CIE SVM≤0.4,Meets the flicker free standard（IEEE Std 1789-2015） |
| Line regulation |
±1% @Full load |
| Load regulation |
±3% @Full load |
| Turn on delay Time |
500ms@230VAC |
| Ripple and Noise |
480mVp-p@230VAC |
| Protection |
Short circuit |
Hiccup protection, Auto-recovery after Fault Clearance |
| Overcurrent |
Hiccup protection, Auto-recovery after Fault Clearance |
| Overload |
Overload protection at 130%-150% load; hiccup mode, output returns to normal after fault cleared. |
| Overvoltage |
Hiccup protection, Auto-recovery after Fault Clearance |
| Overtemperature |
Hiccup protection, Auto-recovery after Fault Clearance |
| Safety& EMC |
Surge |
L-N:1KV |
| Withstand Voltage |
I/P-O/P: 3750VAC/1min/5mA |
| Safety Standards |
CCC (China) GB19510.1，GB19510.14 TUV (Germany) EN61347-1，EN61347-2-13，EN62493 |
|
CB (CBmember states) IEC61347-1，IEC61347-2-13 CE (European Union)EN61347-1，EN61347-2-13，EN62384 |
|
RCM (Australia) AS 61347-1，AS 61347-2-13 ENEC (Europe) EN61347-1，EN61347-2-13，EN62384 |
| EMC Immunity |
EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61547 |
| Environment |
Working Temp |
-20℃…45℃ |
| Storage Temp |
-40℃…85℃ |
| Storage Humidity |
20-90%RH (No condensation) |
