| Input |
Efficiency |
>84%@120VAC, >86%@277VAC Full load |
| Frequency |
0/50/60Hz |
| Voltage |
120VAC-277VAC |
| Voltage(DC) |
120VDC-280VDC |
| PF |
0.95@120VAC, 0.9@277VAC, Full load |
| THD(full load) |
10%@120VAC, 15%@277VAC, Full load |
| Current |
0.65Amax@120VAC, 0.28A@277VAC |
| Current(DC) |
0.60Amax@120VDC, 0.31A@277VDC |
| Inrush Current |
22A@120VAC 244us 51A@277VAC240us |
| Standby Power |
<1W@120VAC |
| No load power |
<2W@120VAC |
| Output |
Current |
200-1200mA (Default current: 950mA) |
| Voltage |
30-56V *(Triac dimming above 20V has better dimming effect) |
| Power |
60W max *(Triac dimming with a load of 20W or more has better dimming effect) |
| Channel |
1 |
| No load output voltage |
59V Max |
| Current Accuracy |
±5% |
| LF current ripple(<120Hz) |
5%@30-56V, 1200mA |
| Auxiliary Power (Vaux) |
CV:12V(0-100mA) In Triac dimming mode, no load is required. |
| Turn on time |
≤ 0.75s, at 230Vac (when the light is on) |
| Protection |
Overload |
Current reduction protection, returns to normal after fault cleared. |
| Short circuit |
Turn off the output, and it will recover automatically after the fault is removed |
| Function |
Dimming type |
0-10V ,Potentiometer,PWM,Triac/ELV(@120VAC 60Hz) |
| Dimming range |
3%-100% |
| Dimming curve |
0-10V: linear/Logarithmic curve programmable, Triac/ELV: Logarithmic |
| Flicker |
Flicker free |
| Safety & EMC |
Surge |
L-N:2.5KV (ANSI/IEEE C62.41.1-2002 & c62.41.2-2002 category A, 2.5 kV ringwave) |
| Withstand Voltage |
I/P-O/P: 2000Vac/1min/<5mA, I/P-PG:1500Vac/1min/<5mA, O/P-PG: 500Vac/1min/<5mA, O/P-DIM( Signal port ):500Vac/1min/<5mA |
| Safety standards |
UL8750/UL1310/CSA25013,CSA class P |
| EMI Eission |
EN55015,EN61000-3-2 Class C,IEC61000-3-3 |
| EMC Immunity |
FCC class B(120V)/class A(277V) |
