| Input |
Efficiency |
≥88%@120VAC, ≥90%@230VAC, ≥90%@277VAC, full load |
| Voltage |
120VAC-277VAC |
| Input voltage range |
100VAC-305VAC |
| Frequency Range(Hz) |
50/60Hz |
| AC Current(max) |
1.2A@120VAC, 0.62A@230VAC, 0.53A@277VAC |
| PF |
≥0.95@120VAC, ≥0.95@230VAC, ≥0.95@277VAC, full load |
| THD |
<10%@120VAC, <10%@230VAC, <15%@277VAC, full load |
| Inrush Current(max) |
Cold start, 30.7A@120VAC 276us, 82.2A@277VAC 284us |
| No-load power |
<0.5W@120VAC |
| Turn on Time |
<0.75s, @230Vac (When the light begins to shine) |
| Output |
Current |
5A*2 Channel |
| Voltage |
12VDC |
| Voltage Range |
12VDC±3% |
| Power |
60W per channel, total 120W |
| Channel |
2 |
| Line Regulation |
±1% @full load |
| Load Regulation |
±3% @full load |
| PstLM |
≤1 |
| SVM |
≤0.4 |
| Protection |
Short Circuit |
No output, Auto-recovery after Fault Clearance |
| Overload |
No output, Auto-recovery after Fault Clearance |
| Overcurrent |
No output, Auto-recovery after Fault Clearance |
| Overtemperature |
Reduce power 50%, auto-restart after normal temperature |
| Safety&EMC |
Surge |
L-N: 6kV, L-PE: 6kV, N-PE: 6kV, L&N-PE: 6kV |
| Withstand Voltage |
I/P-O/P: 3000Vac/1min/<5mA I/P-PE:1500Vac/1min/<5mA O/P-PE:500Vac/1min/<5mA |
| Safety standards |
UL8750,EN61347-1,EN61347-2-13 |
| EMI |
EN55015, FCC Part 15 Class B @ 120~277V |
| Others |
Working Temp. |
-40℃~+60℃ (-40°F~140°F) |
| Storage Temp., Humidity |
-40℃~85℃ (-40°F~185°F), 20-90%RH |
| tc |
90℃ (194°F) for safety & life |
| Material |
Metal |
| IP Rating |
IP67 |
| Lifetime |
50,000h@tc:90℃ (194°F) |
| Warranty Condition |
5 years |
| Switch Cycle |
25,000 times |
| Dimension |
165*67.5*35mm(L*W*H) 6.49*2.66*1.38 In |
| Packing(weight) |
Net weight: 676g(1.49 lb)±5%/PCS; 20 PCS/Carton;13.52kg(29.8lb)±5%/Carton; Carton Size: 368x220x210mm(14.49×8.66×8.26lb)(L*W*H) |
