| Input |
Efficiency |
88%@120VAC, 91%@277VAC, Full load |
| Voltage |
120VAC-277VAC |
| Frequency |
50/60Hz |
| Current |
0.95Amax@120VAC, 0.55Amax@230VAC, 0.45Amax@277VAC, Full load |
| Power Factor |
≥0.95@120VAC, ≥0.90@277VAC, Full load |
| THD |
<20%@120VAC, <20%@277VAC, Full load |
| Inrush Current |
Cold start, 28A@120VAC 220us, 70A@277VAC 150us |
| No load power |
< 0.5W |
| Output |
Voltage |
24VDC |
| Voltage Accuracy |
±5% |
| Current |
4.0A |
| Power |
96W |
| Channel |
1 |
| R & N (Max) |
≤300mV Vp-p |
| Over power limit |
≤104% |
| Turn On Time |
<0.75s, @120Vac (When the light begins to shine) |
| Protection |
Short circuit |
Shut down output, Auto-recovery after Fault Clearance |
| Overload |
Hiccup Protection, Auto-recovery after Fault Clearance |
| Overcurrent |
Hiccup Protection, Auto-recovery after Fault Clearance |
| Over temperature |
Output power drops to 50% at 75-80°C ambient (Tc ≈95°C-100°C ), recovering automatically when temperature normalizes. |
| Safety & EMC |
Surge |
L-N:6kV, L-N-PE: 6kV |
| Withstand Voltage |
I/P-O/P: 2000VAC/1min/5mA; I/P-PE: 1500VAC/1min/5mA; O/P-PE: 500VAC/1min/5mA; |
| Safety standards |
EN61347-1, EN61347-2-13; UL8750:2015 Ed.2+R:07Dec2022, UL1310, CSA-C22.2 No. 250.13:2022 Ed.5 |
| EMI Emission |
EN55015, EN61000-3-2 Class C,IEC61000-3-3; FCC Part 15 Class B(120V)/Class A(277V) |
| EMS lmmunity |
EN61547, EN61000-4-2, 3, 4, 5, 6, 8, 11 |
| Insulation Resisance |
5MΩ |
| Others |
Working Temp. |
-40℃…+60℃(-40°F~140°F) |
| Storage Temp.; Humidity |
-40℃…+85℃(-40°F~194°F), 20-90%RH |
| Tc |
90℃( 194°F ) for safety & 80℃( 176°F ) for life |
| Material |
Metal |
| IP Rating |
IP65 |
| Lifetime |
50,000h@tc:80℃( 176°F ) |
| Warranty Condition |
5 years |
| Switch Cycle |
>25,000 times |
| Packing Size |
Net weight: TBDg (– lb)±5%/PCS; 12PCS/Carton;–kg(– lb)±5%/Carton; Carton Size: 314*263*249mm(12.36*10.35*9.8 Inch)(L*W*H) |
| Dimension |
244*106*41.5mm (9.61*4.17*1.63 Inch)(L*W*H) |
