  • 12W 120~350mA*2ch 0/1-10V CC Driver EUP12A-2HMC

    12W 120~350mA*2ch 0/1-10V CC Driver EUP12A-2HMC

    12W 120~350mA*2ch 0/1-10V CC Driver EUP12A-2HMC UP12Z-2HMC is an LED driver that can provide 120 / 150 / 180, 200 / 240, 270 / 300 / 350 ma current. The output current can be set through the DP dip switch profile to achieve wireless dimming and color matching through ZigBee. Features 1. Two channel output, output current level selectable by DIP S.W. 2. High efficiency up to 85 % 3. Built-in active PFC function 4. Protections: Short circuit, over load, over Voltage 5. Suitable for indoor LED l...
  • 20W 350~700mA*2ch 0/1-10V CC Driver EUP20A-2HMC

    20W 350~700mA*2ch 0/1-10V CC Driver EUP20A-2HMC

    20W 350~700mA*2ch 0/1-10V CC Driver EUP20A-2HMC EUP20A-2HMC is a 20W AC/DC constant current mode output LED driver featuring the multiple levels selectable by DIP switch. Features ·Two channel output, output current level selectable by DIP S.W. ·High efficiency up to 85 % ·Built-in active PFC function ·Protections: Short circuit, over load, over Voltage ·Suitable for indoor LED lighting application, such as down light, panel light, and so on Technical Parameters Model EUP20A-2HMC Input E...
  • 20W 350~700mA*2ch 0/1-10V CC Driver EUP20A-2HMC(Small Size)

    20W 350~700mA*2ch 0/1-10V CC Driver EUP20A-2HMC(Small Size)

    20W 350~700mA*2ch 0/1-10V CC Driver EUP20A-2HMC(Small Size) EUP20A-2HMC is a 20W AC/DC constant current mode unable White output LED driver featuring the multiple levels selectable by DIP switch. Features · Two channel output, output current level selectable by DIP S.W. · High efficiency up to 85 % · Built-in active PFC function · Protections: Short circuit, over load, over Voltage · Suitable for indoor LED lighting application, such as down light, panel light, and so on Technical Parameters ...
  • 75W 24VDC 0/1-10V CV Driver EUP75A-1H24V-1

    75W 24VDC 0/1-10V CV Driver EUP75A-1H24V-1

    75W 24VDC CV 1-10V Driver EUP75A-1H24V-1 EUP75A-1H24V-1 is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Product Features ·Single channel constant voltage output,3.1A Max ·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal) ·High input voltage of 220VAC ~ 240VAC ·Dimming range of 0-100%, and dimming effect smooth,...
  • 40W 750~1100mA*2ch 0/1-10V CC Driver EUP40A-2HMC

    40W 750~1100mA*2ch 0/1-10V CC Driver EUP40A-2HMC

    40W 750~1100mA*2ch 0-10V CC Driver EUP40A-2HMC EUP40A-2HMC is a 40W AC/DC constant current mode output LED driver featuring the multiple levels selectable by DIP switch. Features ·Two channel output, output current level selectable by DIP S.W. ·High efficiency up to 88 % ·Built-in active PFC function ·Protections: Short circuit, over load, over Voltage ·Suitable for indoor LED lighting application, such as down light, panel light, and so on Technical Parameters Model EUP40A-2HMC   &...
  • 40W 415/620/830mA*2ch 0-10V CC Driver EULP40A-2WMC

    40W 415/620/830mA*2ch 0-10V CC Driver EULP40A-2WMC

    40W 415/620/830mA*2ch 0-10V CC Driver EULP40A-2WMC EULP40A-2WMC is a 40W AC/DC constant current mode output LED driver featuring the multiple levels selectable by switch. EULP40A-2WMC can be connected to 0-10V main controller to achieve a smooth dimming effect. Features · 2 channel output, output current level selectable by DIP S.W. · Wide input voltage of 120VAC~277VAC · Meeting UL class2 standard · High efficiency up to 85% · Built-in active PFC function · Logarithmic dimming, dimming effec...
  • 135W 12VDC 0/1-10V CV Driver EUP135A-1W12V-1

    135W 12VDC 0/1-10V CV Driver EUP135A-1W12V-1

    135W 12VDC 1-10V Constant Voltage Dimmable Driver EUP135A-1W12V-1 Feature 1. Signal channel constant voltage, 12VDC 2. Support 1-10V analog dimming signal, passive or active signal 3. Wide input voltage of 100-240VAC 4. High efficiency up to 90% 5. 100% output when no dimming signal input, can be used as normal power supply 6. Dimming effect smooth, no flicker 7. Over current protection, over voltage protection, short circuit protection 8. Suitable for indoor LED lighting application Technica...
  • 80W 830/1250/1600mA*2ch 0-10V CC Driver EULP80A-2WMC

    80W 830/1250/1600mA*2ch 0-10V CC Driver EULP80A-2WMC

    80W 830/1250/1600mA*2ch 0-10V CC Driver EULP80A-2WMC EULP80A-2WMC is a 80W AC/DC constant current mode output LED driver featuring the multiple levels selectable by switch. EULP80A-2HMC can be connected to 0-10V main controller to achieve a smooth dimming effect. Features ·2 channel output, output current level selectable by DIP S.W. · Wide input voltage of 120VAC~277VAC · Meeting UL class2 standard · High efficiency up to 85% · Built-in active PFC function · Logarithmic dimming, dimming effe...
  • 150W 24VDC 0/1-10V CV Driver EUP150A-1W24V-1

    150W 24VDC 0/1-10V CV Driver EUP150A-1W24V-1

    150W 24VDC 1-10V LED Constant Voltage Dimmable Driver EUP150A-1W24V-1 Feature 1. Signal channel constant voltage, 24V 2. Support 1-10V analog dimming signal, passive or active signal 3. Wide input voltage of 100-240VAC 4. High efficiency up to 90% 5. 100% output when no dimming signal input, can be used as normal power supply 6. Dimming effect smooth, no flicker 7. Over current protection, over voltage protection, short circuit protection 8. Suitable for indoor LED lighting application Techn...
  • 75W 24VDC 0/1-10V CV Driver LCP75A-1H24V

    75W 24VDC 0/1-10V CV Driver LCP75A-1H24V

    75W 24VDC 3.12A*1ch 220-240VAC Constant Voltage 0-10V Driver LCP75A-1H24V LCP75A-1H24V is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features 1. Single channel constant voltage output, 3.12A max. 2. High input voltage of 220VAC ~ 240VAC 3. Dimming effect smooth, no flicker 4. Over load protection; over voltage protection; short circuit protecti...
  • 150W 24VDC 0/1-10V CV Driver LCP150A-1H24V

    150W 24VDC 0/1-10V CV Driver LCP150A-1H24V

    150W 24VDC 0/1-10V CV Driver LCP150A-1H24V LCP150A-1H24V is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features · Signal channel constant voltage, 24VDC output · Support passive 0/1-10V analog dimming signal · Dimming range from 0-100%, LED start at 0.1% possible · Wide range voltage Input 220-240VAC · High efficiency: up to 92% · High PF:0.98@230V...
  • 75W 24V 2ch 0/1-10V CV Driver LCP75A-2W24V

    75W 24V 2ch 0/1-10V CV Driver LCP75A-2W24V

    LCP75A-2W24V is a constant voltage mode output LED driver, adjustment of brightness and colour temperature,Dimming Range 0.1%-100%。 Product Features ·Double channel constant voltage output,3.125A Max ·High input voltage of 120VAC ~ 277VAC ·Dimming effect smooth, no flicker ·Over load protection; short circuit protection ·IP20, suitable for indoor LED lighting application Technical Parameters Model LCP75A-2W24V Input Efficiency 92%@230VAC,Full load Voltage 120VAC-277VAC Frequency Ra...
