  • 12W 120~350mA*1ch DALI&0/1-10V CC Driver EUP12AD-1HMC-M

    12W 120~350mA*1ch DALI&0/1-10V CC Driver EUP12AD-1HMC-M

    12W 120~350mA*1ch DALI&0/1-10V CC Driver EUP12AD-1HMC-M EUP12AD-1HMC-M is a constant current output mode LED driver. Support DALI dimming function, Touch DIM (Push DIM) function, 0/1-10V Dimming function. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features ·Single channel output, output current level selectable by DIP S.W. ·Support DALI-2 dimming function, Touch DIM ...
  • 30W 550~900mA*1ch DALI&0/1-10V CC Driver EUP30AD-1HMC-M

    30W 550~900mA*1ch DALI&0/1-10V CC Driver EUP30AD-1HMC-M

    30W 550~900mA*1ch DALI&0/1-10V CC Driver EUP30AD-1HMC-M EUP30AD-1HMC-M is a constant current output mode LED driver. Support DALI dimming function, Touch DIM (Push DIM) function, 0/1-10V Dimming function. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features ·Single channel output, output current level selectable by DIP S.W. ·Support DALI dimming function, Touch DIM (P...
  • 40W 750~1100mA*1ch DALI&0/1-10V CC Driver EUP40AD-1HMC-M

    40W 750~1100mA*1ch DALI&0/1-10V CC Driver EUP40AD-1HMC-M

    40W 750~1100mA*1ch DALI&0/1-10V CC Driver EUP40AD-1HMC-M EUP40AD-1HMC-M is a constant current output mode LED driver. Support DALI dimming function, Touch DIM (Push DIM) function, 0/1-10V Dimming function. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features · Single channel output, output current level selectable by DIP S.W. · Support DALI2.0 dimming function, Touch ...
  • 45W 700~1050mA*1ch DALI&0/1-10V CC Driver PCP45AD-1HMC

    45W 700~1050mA*1ch DALI&0/1-10V CC Driver PCP45AD-1HMC

    45W 700~1050mA DALI&0/1-10V CC Driver PCP45AD-1HMC PCP45AD-1HMC is a constant current output mode LED driver. Support DALI dimming function, Touch DIM (Push DIM) function, 0/1-10V Dimming function. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable via DIP S.W. 2. Support DALI dimming function, Touch DIM (Pu...
  • 45W 500~1400mA*1ch DALI&0/1-10V CC Driver PSP45AD-1HMC

    45W 500~1400mA*1ch DALI&0/1-10V CC Driver PSP45AD-1HMC

    45W 500~1400mA DALI&0/1-10V CC Driver PSP45AD-1HMC PSP45AD-1HMC is a constant current output mode LED driver. Support DALI dimming function, Touch DIM (Push DIM) function, 0/1-10V Dimming function. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable via DIP S.W. 2. Support DALI dimming function, Touch DIM (Pu...
  • 30W 250-1050mA*1ch DALI&0/1-10V CC Driver SUP30AD-1WPC-WS

    30W 250-1050mA*1ch DALI&0/1-10V CC Driver SUP30AD-1WPC-WS

    30W 250-1050mA*1ch DALI&0/1-10V CC Driver SUP30AD-1WPC-WS SUP30AD-1WPC-WS is a constant current output LED dimming driver. The driver supports DALI, Touch DIM/Push DIM, 0-10V edge signal, PWM and adjustable resistor signals achieve smooth dimming effect. Features · Single channel output, the output current can be selected through software. · Five in one dimming (DALI, 0-10V, PWM, Adjustable resistance, Push DIM ) · Adhere to the DALI protocol standard IEC62386-207 Ed2.0 · Class 2 power su...
  • 40W 650~1000mA*1ch DALI CC Driver EUPA40D-1HMC

    40W 650~1000mA*1ch DALI CC Driver EUPA40D-1HMC

    40W 650~1000mA*1ch DALI CC Driver EUPA40D-1HMC EUPA40D-1HMC is an LED driver that can provide 8 levels of current: 650/700/750/800/850/900/950/1000mA. The output current can be easily set through DIP dip switches, dimmed with DALI main control/Touch DIM switches, and the curve is flat Smooth and without flickering. Features ·Single channel constant current output, multi-level current optional ·Following the DALI protocol standard IEC62386-207 Ed2.0 ·Support Touch DIM function ·High voltage in...
  • 50W 450~1400mA*1ch DALI&0-10V CC Driver SUP50AD-1WPC-WS

    50W 450~1400mA*1ch DALI&0-10V CC Driver SUP50AD-1WPC-WS

    50W 450~1400mA*1ch DALI&0-10V CC Driver SUP50AD-1WPC-WS SUP50AD-1WPC-WS is a constant current output LED dimming driver. The driver supports DALI, Touch DIM/Push DIM, 0-10V edge signal, PWM and adjustable resistor signals achieve smooth dimming effect. Features · Single channel output, the output current can be selected through software. · Five in one dimming (DALI, 0-10V, PWM, Adjustable resistance, Push DIM ) · Adhere to the DALI protocol standard IEC62386-207 Ed2.0 · Class 2 power supp...
  • 14W 120~350mA*1ch DALI DC-DC CC Driver BMP14D-1SMC

    14W 120~350mA*1ch DALI DC-DC CC Driver BMP14D-1SMC

    14W 48VDC 120/150/180/210/240/270/300/350mA DALI DC-DC Driver BMP14D-1SMC Features 1. Output current 120-350mA, can be set via DIP switch 2. Compliant with DALI 2.0 standard protocol 3. Mixed dimming PWM+CCR, no flicker 4. Short circuit protection, overload protection,no load protection,Input reverse connection 5. Built-in driver 6. Hot plug for input port and non polarized Technical Parameters Model BMP14D-1SMC Input Efficiency 93% Voltage 42-52VDC Current 0.63Amax@48VDC, full load ...
  • 21W 700~1050mA*1ch DALI DC-DC CC Driver BMP21D-1SMC

    21W 700~1050mA*1ch DALI DC-DC CC Driver BMP21D-1SMC

    21W 700/750/800/850/900/950/1000/1050mA DALI DC-DC Driver BMP21D-1SMC BMP21D-1SMC is a DC/DC constant current output LED driver.The output current can be set via DIP switch.It can be controlled by DALI master, and the dimming curve is smooth and flicker free. Features 1. Output current 700-1050mA, can be set via DIP switch 2. Compliant with DALI 2.0 standard protocol 3. Mixed dimming PWM+CCR, no flicker 4. Short circuit protection, overload protection,no load protection,Input reverse connecti...
  • 28W 350~700mA*1ch DALI DC-DC CC Driver BMP28D-1SMC

    28W 350~700mA*1ch DALI DC-DC CC Driver BMP28D-1SMC

    28W 350/400/450/500/550/600/650/700mA DALI DC-DC Driver BMP28D-1SMC is a DC/DC constant current output LED driver.The output current can be set via DIP switch.It can be controlled by DALI master, and the dimming curve is smooth and flicker free. Features 1. utput current 350-700mA, can be set via DIP switch 2. Compliant with DALI 2.0 standard protocol 3. Mixed dimming PWM+CCR, no flicker 4. Short circuit protection, overload protection,no load protection,Input reverse connection 5. Built-in d...
  • 14W 120~350mA*2ch DALI DC-DC CC Driver BMP14D-2SMC

    14W 120~350mA*2ch DALI DC-DC CC Driver BMP14D-2SMC

    14W 120~350mA*2ch DALI DC-DC CC Driver BMP14D-2SMC Features ·Two channel output, output current level selectable by DIP S.W. ·Meet DALI Protocol IEC 62386-209 ·High efficiency up to 93 % ·Built-in active PFC function ·Dimming effect smooth, no flicker ·Protections: Short circuit, over load, Input reverse connection ·Suitable for indoor LED lighting application, such as down light, panel light, and so on Technical Parameters Model BMP14D-2SMC    Input Efficiency 93%@48VDC, full load ...
