200~240V Triac Dimmer Walldim107

Short Description:

  • Item No.: Walldim107

Product Detail

Product Tags

200~240V Triac Dimmer Switch Walldim107

Product Features

1. Support trailing edge (ELV) dimming

2. ABS material, high flame retardant

3. Fashion, and easy to use

4. Can be installed in the wall box

5. Suitable for ELV dimming driver, incandescent lamps,and other loads

6. Installation in appliance box to DIN 49073 , used in the study, bedroom, restaurant, bars
and other places need dimming control

Technical Parameters

Model WALLDIM107
Input Power 200~240V AC 50Hz
Input frequency 50Hz
Load type Incandescent lamps: 200W
Dimmable LED: 200W
TRIAC dimming driver: 200W
Panel color Ivory-white
Panel size 86*86*42mm(W*H*D)
Packing size 103*103*50mm(W*H*D)
G.W. 140g
Working Temperature -10 ℃ ~40 ℃
Relative humidity 20-90% RH
