Products LED driver, Products LED controller, Products LED dimmer - Euchips

40W 750/800/850/900mA*2ch Non-dimmable CC Driver PUS40-2HMC-S8

40W 750/800/850/900mA*2ch Non-dimmable CC Driver 40W PUS40-2HMC-S8 PUS40-2HMC-S8 is a constant current output LED driver. The output current and color temperature can be adjusted by dip switch. Features · Dual channel constant current output, multi-level current optional · Built-in active PFC function · No stroboscopic · Overvoltage protection, load protection, short circuit protection · Suitable for LED indoor lamps, such as downlights, spotlights, panel lights, etc Technical Parameters ...

detail
Enclosures For Remote Dimming Drivers EUA-IPS-H104

Enclosures For Remote Dimming Drivers EUA-IPS-H104 All remote drivers require enclosures by code. Euchips makes your specification process easier by offering different driver enclosures to fulfill all of your project needs. See options below. 6-Driver pre-wired Enclosure houses up to 6 dimming drivers.

detail
24W 170/200/230mA Non-dimmable CC Driver LTS24-1HMC

24W 170/200/230mA Non-dimmable CC Driver LTS24-1HMC The LTS24-1HMC is a 24W constant-current LED driver featuring an ultra-slim profile design, widely used in track lighting applications. Features Single-channel constant current output High voltage input: 220VAC ~ 240VAC High efficiency up to 89% No-load power consumption ≤1W, THD <15% Ultra-thin design Protections: Open-circuit, short-circuit, over-temperature Technical Parameters Model LTS24-1HMC Input Input Voltage 220VAC-24...

detail
12-24VDC 15mA DALI to 0-10V Analog Signal Converter DALI6000

12V 24V DALI 0-10V Analog Signal Converter DALI6000 Feature 1. DALI to 0-10V Converter 2. 1 channel 0-10V Analog Signal output 3. Drive capability: max 15mA/channel 4. Meets DALI protocol IEC62386/IEC60929 5. Support automatic addressing and address extensions 6. Input VoltageㄩDC12 -24V 7. Security Level: 2 Level Technical Parameter Product Name DALI 0-10V Analog Signal 12V 24V Converter Item DALI6000 Conversion Channel 1 Channel Input Voltage DC12 -24V Input Signal DALI Sig...

detail
6W 24VDC Non-dimmable CV Driver PCE6-1U24V

6W 24VDC Non-dimmable CV Driver PCE6-1U24V PCE6-1U24V is a 6W constant voltage LED driver, with Compact body design, minimum mounting aperture 28mm. Features · Single channel constant Voltage output · Wide voltage input: 100-277VAC · Compact size · Short circuit, over load, over current, Over Temperature protections · Suitable for constant voltage lamps Technical Parameters Model PCE6-1U24V Input Efficiency ≥83% @100/120/230/277VAC,Full load Voltage 1...

detail
Drivers and Enclosure Guide EUA-IPS-H104

Drivers and Enclosure Guide EUA-IPS-H104 Enclosures (Optional) All remote drivers require enclosures by code. Euchips makes your specification process easier by offering different driver enclosures to fulfill all of your project needs. See options below. EUCHIPS offers applications assistance for configuration of remote drivers and remote driver enclosures. 1.Contact your local euchips representative with your project’s light fixture specification and zoning information. 2.EUCHIPSR...

detail
24VDC 20mA*4ch DMX to 0-10V Analog Signal Converter PX24608

DMX to 0-10V Analog Signal Converter PX24608 Summarize Thank you for using PX series of DMX512 Decoder. PX series adopt the advanced micro-computer control?technology, it converts the DMX-512/1990 standard digital signal adopted widely in international to 0-10V/1-10V signal.4 Channels output, output driver 20 mA per channel.it can be used to control?0-10V/1-10V dimmer. It is mainly used for signal convert betwwen DMX Master and 0-10V/1-10V(DMX to 1-10V Converter) Dimmer. Feature 1. Meet t...

detail
12-22.5Vdc DALI to 0-10V Converter EUD-A02

12-22.5Vdc DALI to 0-10V Converter EUD-A02 The DA-010 is a non-isolated signal converter translating the DALI command into 0-10V dimmng signal for LED driver with 0-10V dimming control. This design complies to IEC 62386-101, 102, 207 DALI standard protocol. It is a perfect solution to convert standard fixture to be controlled in DALI control environment. Technical Parameters Model EUD-A02 OUTPUT Output Voltage 0-10Vdc Output 0-10 SINK Current ≤ 2mA Voltage Tolerance ±5% INPUT V...

detail
100-240VAC DALI to Phase Cut Signal Converter DALI-GSC-5

100-240VAC DALI to Phase Cut Signal Converter DALI-GSC-5 Features · Comply with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2 · Thyristor phase-cutting dimming controller supporting DALI and Touch DIM dimming · Controlled LED thyristor dimming power supply, incandescent lamp, AC low voltage lamp, etc · Wide voltage input 100-240VAC · One DALI address, one channel output, maximum output current is 1.8A Technical Parameters Input control signal DALI signal or Touch switch signal ...

detail
300W 24VDC DALI CV Driver LM300D-1H24V-A

300W 24VDC DALI CV Driver LM300D-1H24V-A LM300D-1H24V-A is a constant voltage mode output LED driver. This driver complies with DALI standard protocol IEC 62386,provides dimming function DALI and Touch DIM to achieve a smooth dimming effect. Features · Single channel constant voltage output,12.5A Max · Meet DALI protocol IEC 62386 · Dimming effect smooth, no flicker · Overload protection, overcurrent protection, short circuit protection · IP20, suitable for indoor LED lighting application Tec...

detail
