Waterproof Drivers LED driver, Waterproof Drivers LED controller, Waterproof Drivers LED dimmer - Euchips

100W 12VDC Non-dimmable Waterproof CV Driver PEE100-1H12V

100W 12VDC Non-dimmable CV Driver PEE100-1H12V Features ·full power output ·Insolated PC design ·Isolated design,safe and reliable ·Protections:Over load,Short circuit,over Current ·Protection grades is as high as IP65 ·5 years warranty ·No Flicker Technical Parameters Model PEE100-1H12V Input Efficiency ≥89%@230VAC, Full load Voltage 220VAC-240VAC Frequency 50/60Hz Power Factor ≥0.95@230VAC, full load THD <10%@230VAC, full load Current 0.63Amax@230VAC No load output volta...

detail
100W 24VDC Non-dimmable Waterproof CV Driver PEE100-1H24V

100W 24VDC Non-dimmable CV Driver PEE100-1H24V Features ·full power output ·Insolated PC design ·Isolated design,safe and reliable ·Protections:Over Voltage,Short circuit,over Current ·Protection grades is as high as IP65 ·5 years warranty ·No Flicker Technical Parameters Model PEE100-1H24V Input Efficiency >88%@230VAC, Full load Voltage 220VAC-240VAC Frequency 50/60Hz Power Factor ≥0.95@230VAC, full load THD <10%@230VAC, full load Current 0.624Amax@230VAC No load outpu...

detail
100W 48VDC Non-dimmable CV Driver PEE100-1H48V

100W 48VDC Non-dimmable CV Driver PEE100-1H48V Features ·full power output ·Insolated PC design ·Isolated design,safe and reliable ·Protections:Over Voltage,Short circuit,over Current ·Protection grades is as high as IP65 ·5 years warranty ·No Flicker Technical Parameters Model PEE100-1H48V Input Efficiency >89%@230VAC, Full load Voltage 220VAC-240VAC Frequency 50/60Hz Power Factor ≥0.95@230VAC, full load THD <10%@230VAC, full load Current 0.63Amax@230VAC ...

detail
150W 24VDC Non-dimmable Waterproof CV Driver PEE150-1H24V

150W 24VDC Non-dimmable Waterproof CV Driver PEE150-1H24V Features · full power output · Insolated PC design · Isolated design,safe and reliable · Protections:Over load,Short circuit,over Current · Protection grades is as high as IP65 · 5 years warranty · Flicker Fre Technical Parameters Model PEE150-1H24V Input Efficiency ≥93%@230VAC, Full load Voltage 220VAC-240VAC Frequency 50/60Hz Power Factor ≥0.95@230VAC, full load Current 0.89Amax@230VAC In...

detail
240W 12VDC DALI Waterproof Ultra-thin CV Driver UWP240D-1M12V

240W 12VDC Ultra-thin Waterproof DALI Constant Voltage Driver UWP240D-1M12V UWP240D-1M12V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master / Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features 1. Single channel output with 12V CV direct current 2. Wide voltage input range from 100VAC to 240VAC 3. with built-in active PFC function 4. Meet DALI protocol I...

detail
240W 24VDC DALI Waterproof Ultra-thin CV Driver UWP240D-1M24V

240W 24VDC Ultra-thin Waterproof DALI Constant Voltage Driver UWP240D-1M24V UWP240D-1M24V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master / Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features 1. Single channel output with 24V CV direct current 2. Wide voltage input range from 100VAC to 240VAC 3. with built-in active PFC function 4. Meet DALI protocol I...

detail
320W 24VDC DALI Waterproof Ultra-thin CV Driver UWP320D-1M24V

320W 24VDC Waterproof DALI CV Driver UWP320D-1M24V UWP320D-1M24V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master/Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features ·Single channel output with 24V CV direct current ·Wide voltage input range from 100VAC to 240VAC ·With built-in active PFC function ·Meet DALI protocol IEC 62386-207 ·Support Touch DIM(Push...

detail
40W 24VDC Non-dimmable Waterproof CV Driver OWP40-1H24V

40W 24VDC Waterproof Non-dimming CV Driver OWP40-1H24V Features 1. Single channel output with 24V CV direct current 2. Wide voltage input range from 220VAC to 240VAC 3. With built-in active PFC function 4. Ultra-thin design, Waterproof level IP67, High effciency up to 87% 5. Dimming effect smooth, no flicker 6. Protections: Short circuit, over load, lightning protection 7. suitable for LED CV lighting, such as LED module, LED strip light, LED tube, and so on Technical Parameters Model OWP...

detail
75W 12VDC DALI Waterproof CV Driver OWP75D-1H12V

75W 12VDC Waterproof DALI Constant Voltage Driver OWP75D-1M12V OWP75D-1H12V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master/Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features 1. Single channel output with 12V CV direct current 2. Voltage input range from 220VAC to 240VAC 3. Built-in active PFC function 4. Meet DALI protocol IEC 62386-207 5. Support Tou...

detail
75W 12VDC DALI Waterproof CV Driver OWP75D-1W12V

75W 12VDC DALI Waterproof CV Driver OWP75D-1W12V WP75D-1W12V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master/Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features · Single channel output with 12V CV direct current · Voltage input range from 120VAC to 277VAC · Built-in active PFC function · Meet DALI protocol IEC 62386-207 · Support Touch DIM(Push DIM) fun...

detail
75W 24VDC DALI Waterproof CV Driver OWP75D-1W24V

75W 24VDC DALI Waterproof CV Driver OWP75D-1W24V OWP75D-1W24V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master/Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features · Single channel output with 24V CV direct current · Voltage input range from 120VAC to 277VAC · Built-in active PFC function · Meet DALI protocol IEC 62386-207 · Support Touch DIM(Push DIM) fu...

detail
75W 48VDC DALI Waterproof CV Driver OWP75D-1W48V

75W 48VDC DALI Waterproof CV Driver OWP75D-1W48V OWP75D-1W48V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master/Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features · Single channel output with 48V CV direct current · Voltage input range from 120VAC to 277VAC · Built-in active PFC function · Meet DALI protocol IEC 62386-207 · Support Touch DIM(Push DIM) fu...

detail
