| Input |
Efficiency |
≥76%@120VAC, ≥81%@277VAC, full load |
| Voltage |
120VAC-277VAC |
| Frequency Range(Hz) |
50/60Hz |
| AC Current(max) |
0.56Amax @120VAC, 0.25Amax@230VAC, 0.2Amax@277VAC |
| PF |
≥0.95@120VAC, ≥0.9@277VAC, full load |
| THD |
<10%@120VAC, <15%@277VAC, full load |
| Inrush Current(max) |
Cold start,5A@120VAC 590us 12A@277VAC 600us |
| Standby power |
<2.5W@120VAC |
| No load power |
<2.5W@120VAC |
| Turn on delay Time |
<0.75s, @120Vac (When the light begins to shine) |
| Output |
Current |
1.25A |
| Voltage |
24VDC |
| Voltage Range |
24VDC ±5% |
| Power |
30W |
| Channel |
1 |
| PWM Frequency |
20K Hz |
| Function |
Dimming Type |
0-10V, Potentiometer, PWM, Triac/ELV(@120VAC 60Hz) |
| Dimming Range |
1%-100%(0-10V) 1%-100%(TRIAC/ELV) |
| Dimming curve |
Logarithm (for 0-10V & Tiac/ELV) |
| Flicker |
Flicker free |
| Protection |
Short Circuit |
Shut down output, Auto-recovery after Fault Clearance |
| Over Load |
Hiccup Protection, Auto-recovery after Fault Clearance |
| Over Current |
Current drops, Auto-recovery after Fault Clearance |
| Safety&EMC |
Surge |
L-N: 2.5kV L-N-PE: 2.5kV |
| Withstand Voltage |
I/P-O/P: 2000Vac/1min/<5mA I/P-PE:1500Vac/1min/<5mA O/P-PE:500Vac/1min/<5mA O/P-DIM( Signal port ):500Vac/1min/<5mA |
| Safety standards |
UL8750 UL1310 CSA25013.CSA Class P |
| EMC Eission |
FCC PART15B |
| EMC Immunity |
IEC 61000-4-2-3-4-5-6-8-11 |
| Insulation Resisance |
5MΩ |
| Others |
Working Temp. |
-20℃~+60℃ (-4°F-140°F) |
| Storage Temp., Humidity |
-40℃~85℃ (-40°F-185°F), 20-90%RH |
| tc |
90℃ (194°F) for safety & 75℃ [ 167°F ] for life |
| Material |
Metal |
| IP Rating |
IP65 |
| Lifetime |
50,000h@tc:75℃ (167°F) |
| Warranty Condition |
5 years |
| Switch Cycle |
25,000 times |
| Packing(weight) |
Net weight: TBDg (TBD lb)±5%/PCS; 20PCS/Carton;TBDkg(TBD lb)±5%/Carton; Carton Size: 312*283*178mm(12.28*11.14*7.0Inch)(L*W*H) |
| Dimension |
268*55*35mm(10.55*2.16*1.38 Inch)(L*W*H) |
