75W 24VDC Phase-cut CV Driver EUP75T-1H24V-0

Short Description:

  • Item No.: EUP75T-1H24V-0
  • Input Voltage: 220-240VAC
  • Output Current: 3.1A*1CH
  • Output Voltage: 24VDC
  • Output Power: 75W
  • Dim Mode: Triac/ELV
  • G.W.: 460g
  • Size: 213*54*33mm

Product Detail

Product Tags

75W 24VDC Costant Voltage Dimmable Driver EUP75T-1H24V-0


1. Single-channel constant Voltage output, each channel 3.1A Max.

2. Support leading edge(Triac) and Trailing edge(ELV) dimming

3. Dimming range from 40VAC to 240V AC.

4. Dimming effect smooth, no flicker

5. High efficiency is up to 86%

6. High power factor of 0.99

7. Short circuit protection; Over voltage protection; Over current protection, Over temperature protection

8. Suitable for indoor LED lighting application


Technical Parameters

Product Name 75W 24VDC Triac Constant Voltage Dimmable Driver
Model EUP75T-1H24V-0
Output Channels 1
Voltage 24VDC
Current 3.1A
Power 75W
Voltage Accuracy ±3%
R & N (Max) 200mVp-p
Input Voltage 220VAC – 240VAC
Frequency 50/60Hz
Dimming Voltage Range 40-240VAC
Power Factor ≧0.99@230VAC,full load
Efficiency 86%
Current 0.5Amax@230VAC,full load
Inrush Current Cold start,18.2A(twidth=700 us
measured at 50% Ipeak) @230VAC
Protection Short circuit Close the output, restart to recover since fault condition is removed for 10s
Over Voltage Hiccup, recovers after fault condition is removed
Over Temperature Shut down and auto-restart after normal temperature
Over current Hiccup, recovers after fault condition is removed
Function Dimming Mode Triac/ELV
Others Dimension 213*54*33 mm(L*W*H)
G.W 460g
Working temp. -20℃ ~ 50℃
Relative humidity 20~90% RH
