NA/UL Drivers

Dimming Signal
CC/CV
Input Voltage
Output Voltage
Output Current
Output Power
Output Channel
Application Area
Product Category
Certification
Download CSV Display as Poster
  • 20W 350~700mA*1ch Triac CC Driver PUP20T-1LMC

    20W 350~700mA*1ch Triac CC Driver PUP20T-1LMC

    20W 350~700mA Triac Constant Current Driver PUP20T-1LMC PUP20T-1LMC is a constant current output mode LED driver.The output current can be easily set via DIP switch.The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, achieve a smooth dimming effect. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support Leading edge (Triac) and Trailing edge (ELV) dimmer 3. Built-in active PFC function 4. Class Ⅱ power supply. Full protective plastic hou...
  • 40W 500~850mA*1ch Triac CC Driver PUP40T-1LMC-850

    40W 500~850mA*1ch Triac CC Driver PUP40T-1LMC-850

    40W 500~850mA*1ch CV Driver PUP40T-1LMC-850 PUP40T-1LMC-850 is a constant current output mode LED driver.The output current can be easily set via DIP switch.The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, achieve a smooth dimming effect. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support Leading edge (Triac) and Trailing edge (ELV) dimmer 3. Built-in active PFC function 4. Class Ⅱ power supply. Full protective plastic housing ...
  • 40W 850~1200mA*1ch Triac CC Driver PUP40T-1LMC-1200

    40W 850~1200mA*1ch Triac CC Driver PUP40T-1LMC-1200

    40W 850~1200mA*1ch CV Driver PUP40T-1LMC-1200 PUP40T-1LMC-1200 is a constant current output mode LED driver.The output current can be easily set via DIP switch.The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, achieve a smooth dimming effect. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support Leading edge (Triac) and Trailing edge (ELV) dimmer 3. Built-in active PFC function 4. Class Ⅱ power supply. Full protective plastic housin...
  • 10W 120~350mA*1ch 0/1-10V CC Driver PUP10A-1WMC-350

    10W 120~350mA*1ch 0/1-10V CC Driver PUP10A-1WMC-350

    10W 120~350mA 0/1-10V Constant Current Driver PUP10A-1WMC-350 PUP10A-1WMC-350 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 120VAC ~ 277VAC 4...
  • 10W 350~700mA*1ch 0/1-10V CC Driver PUP10A-1WMC-700

    10W 350~700mA*1ch 0/1-10V CC Driver PUP10A-1WMC-700

    10W 350~700mA 0/1-10V Constant Current Driver PUP10A-1WMC-700 PUP10A-1WMC-700 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM 3. Input voltage of 120VAC ~ 277VAC 4. Dimming...
  • 20W 350~700mA*1ch 0/1-10V CC Driver PUP20A-1WMC

    20W 350~700mA*1ch 0/1-10V CC Driver PUP20A-1WMC

    20W 350~700mA 0/1-10V Constant Current Driver PUP20A-1WMC PUP20A-1WMC is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 120VAC ~ 277VAC 4. Dimmin...
  • 40W 500~850mA*1ch 0/1-10V CC Driver PUP40A-1WMC-850

    40W 500~850mA*1ch 0/1-10V CC Driver PUP40A-1WMC-850

    40W 500~850mA 0/1-10V Constant Current Driver PUP40A-1WMC-850 PUP40A-1WMC-850 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 120VAC ~ 277VAC 4...
  • 40W 850~1200mA*1ch 0/1-10V CC Driver PUP40A-1WMC-1200

    40W 850~1200mA*1ch 0/1-10V CC Driver PUP40A-1WMC-1200

    40W 850~1200mA 0/1-10V Constant Current Driver PUP40A-1WMC-1200 PUP40A-1WMC-1200 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode: 0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 120VAC ~ 277V...
  • 60W 12VDC Triac CV Driver MUP60T-1W12V

    60W 12VDC Triac CV Driver MUP60T-1W12V

    60W 12VDC Triac Constant Voltage Driver MUP60T-1W12V MUP60T-1W12V is a constant voltage mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, and can be compatible with the systems of various brands (Philips, Panasonic, Lutron, Simon, ABB, Bunge,Siemens etc.) to achieve a smooth dimming effect. Features 1. Single-channel constant voltage output, 5.0A Max. 2. Support Leading edge (Triac) and Trailing edge (ELV)Dimmer 3. Dimming range from 40VAC to 1...
  • 60W 24VDC Triac CV Driver MUP60T-1W24V

    60W 24VDC Triac CV Driver MUP60T-1W24V

    60W 24VDC Triac Constant Voltage Driver MUP60T-1W24V MUP60T-1W24V is a constant voltage mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, and can be compatible with the systems of various brands (Philips, Panasonic, Lutron, Simon, ABB, Bunge,Siemens etc.) to achieve a smooth dimming effect. Features 1. Single-channel constant voltage output, 2.5A Max. 2. Support Leading edge (Triac) and Trailing edge (ELV)Dimmer 3. Dimming range from 40VAC to 1...
  • 96W 12VDC Triac CV Driver MUP96T-1W12V

    96W 12VDC Triac CV Driver MUP96T-1W12V

    96W 12VDC Triac Constant Voltage Driver MUP96T-1W12V MUP96T-1W12V is a constant voltage mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, and can be compatible with the systems of various brands (Philips, Panasonic, Lutron, Simon, ABB, Bunge,Siemens etc.) to achieve a smooth dimming effect. Features 1. Single-channel constant voltage output, 8A Max. 2. Support Leading edge (Triac) and Trailing edge (ELV)Dimmer 3. Dimming range from 40VAC to 120...
  • 96W 24VDC Triac CV Driver MUP96T-1W24V

    96W 24VDC Triac CV Driver MUP96T-1W24V

    96W 24VDC Triac Constant Voltage Driver MUP96T-1W24V MUP96T-1W24V is a constant voltage mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, and can be compatible with the systems of various brands (Philips, Panasonic, Lutron, Simon, ABB, Bunge,Siemens etc.) to achieve a smooth dimming effect. Features 1. Single-channel constant voltage output, 4A Max. 2. Support Leading edge (Triac) and Trailing edge (ELV)Dimmer 3. Dimming range from 40VAC to 120...
