Products LED driver, Products LED controller, Products LED dimmer - Euchips

60W 1200mA 0-10V CC Driver HUP60A2-1WMC-1200-6C2

60W 1200mA 0-10V CC Driver HUP60A2-1WMC-1200-6C2 Features • Wide input voltage of 108-305Vac • Great Surge 2.5kV(ringwave) • 50,000Hour Life @ Tc=90C • 5 Years Warranty @ Tc<=90C • ±5% Output Current Accuracy • 0-10V • UL Class P, Class 2 • Safety according to UL8750 &UL 1310 Technical Parameters Model HUP60A2-1WMC-1200-6C2 Input Efficiency 86%@120Vac&Full-Load Voltage 120~277VAC Frequency 47~63Hz Power Factor >0.9@120Vac&Full-Load TH...

detail
400W 24VDC Non-dimmable Rainproof CV Driver MRS400-1H24V

400W 24VDC Non-dimmable Rainproof CV Driver MRS400-1H24V Features ·Single group constant voltage DC 24V output ·Design of built-in LED power supply indication and fine-tuning voltage ·Designed with aluminum shell to improve heat dissipation performance ·Ultra thin industrial control certification series with active PFC function,PF ＞0.95 ·The product adopts fan free and noise free natural air cooling mode design ·The internal semi filling process protects the electronic components and has th...

detail
20W 12VDC Non-dimmable Waterproof CV Driver PEE20-1W12V

20W 12VDC Non-dimmable Waterproof CV Driver PEE20-1W12V Features ·Insolated PC design ·Isolated design,safe and reliable ·Protections: Short circuit, Over load, over current ·Protection grades is as high as IP65 ·5 years warranty Technical Parameters Model PEE20-1W12V Input Efficiency ≥84%@230VAC, Full load Voltage 120VAC-277VAC Frequency 50/60Hz Current 0.5Amax@120VAC No load power ≤0.5W PF ≥0.5@120Vac Inrush Current Cold start 37A@230VAC 150us Turn On Delay Tim...

detail
60W 12VDC 0/1-10V CV Driver MUP60A-1W12V

60W 12VDC 0/1-10V CV Driver MUP60A-1W12V MUP60A-1W12V is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features ·Single channel constant voltage output,5.0A Max ·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal) ·High input voltage of 120VAC ~ 277VAC ·Dimming range of 1-100%, and dimming effect smooth, no flick...

detail
10W 120~350mA 0/1-10V CC Driver PUP10A-1WMC-350

10W 120~350mA 0/1-10V Constant Current Driver PUP10A-1WMC-350 PUP10A-1WMC-350 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation. Features 1. Single channel output, output current level selectable by DIP S.W. 2. Support 3-in-1 dimming mode:0/1-10V active signal, adjustable resistance, PWM(A model) 3. Input voltage of 100VAC ~ 240VAC 4...

detail
2.4G Brightness Remote Control RC5

Features 1. Using 2.4G RF remote control, long distance transmission 2. For adjusting the brightness of the lamps 3. Can control a variety of controllers, and can be free to code and clear code 4. Fashion, and easy to use Technical Parameters Item Parameters Power 3VDC(CR2032) Remote Distance 20m Wireless Frequency 2.4Ghz ISM Working Current <20mA Standby Current <4uA Standby Time 6 months Working Temperature -30℃~55℃ Dimension 100*61.5*9mm（L *W *H） Weight ...

detail
60W 24VDC 0/1-10V CV Driver MUP60A-1W24V

60W 24VDC 0/1-10V CC Driver MUP60A-1W24V MUP60A-1W24V is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect. Features ·Single channel constant voltage output,2.5A Max ·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal) ·High input voltage of 120VAC~277VAC ·Dimming range of 1-100%, and dimming effect smooth, no flicker...

detail
20W 24VDC Non-dimmable Waterproof CV Driver PEE20-1W24V

20W 24VDC Non-dimmable Waterproof CV Driver PEE20-1W24V Features ·Insolated PC design ·Isolated design,safe and reliable ·Protections: Short circuit, Over load, over current ·Protection grades is as high as IP65 ·5 years warranty Technical Parameters Model PEE20-1W24V Input Efficiency ≥86%@230VAC, Full load Voltage 120VAC-277VAC Frequency 50/60Hz Current 0.5Amax@120VAC No load power <0.5W Inrush Current Cold start,18A@230VAC 20us Output Current/Voltage/Power 0.833A/...

detail
350~700mA*2ch DMX CC Driver EUP20M-2HMC

350~700mA*2ch DMX CC Driver EUP20M-2HMC EUP20M-2HMC is a 20W AC/DC constant current mode output LED driver featuring the multiple levels selectable by DIP switch and complies with DMX512(1990). EUP20M-2HMC can be connected to DMX main controller or RDM controller to achieve a smooth dimming effect. Features · Single channel output, output current level selectable by DIP S.W. · Meet DMX512(1990) · Support RDM function · Wide input voltage of 220VAC ~ 240VAC · High efficiency up to 86% · Built-...

detail
60W 1200mA 0-10V CC Driver HUP60A2-1BMC-1200-6C2

60W 1200mA 0-10V CC Driver HUP60A2-1BMC-1200-6C2 Features • Wide input voltage of 108-347Vac • Great Surge 2.5kV(ringwave) • 50,000Hour Life @ Tc=90C • 5 Years Warranty @ Tc<=90C • ±5% Output Current Accuracy • 0-10V • UL Class P, Class 2 • Safety according to UL8750 &UL 1310 Technical Parameters Model HUP60A2-1BMC-1200-6C2 Input Efficiency 86%@120Vac&Full-Load Voltage 120~347VAC Frequency 47~63Hz Power Factor >0.9@120Vac&Full-Load TH...

detail
75W 12VDC DALI Waterproof Ultra-thin CV Driver UWP75D-1M12V

75W 12VDC Ultra-thin Waterproof DALI Constant Voltage Driver UWP75D-1M12V UWP75D-1M12V is a dimming driver that can provide constant voltage output. Complies with DALI standard protocol IEC 62386. LED driver featuring the dimming by DALI master / Touch DIM(PushDIM) switch, with smooth dimming curve and are flicker free. Features 1. Single channel output with 12V CV direct current 2. Wide voltage input range from 100VAC to 240VAC 3. with built-in active PFC function 4. Meet DALI protocol IEC ...

detail
35W 24VDC Non-dimmable Waterproof CV Driver PEE35-1W24V

35W 24VDC Non-dimmable Waterproof CV Driver PEE35-1W24V Features ·Insolated PC design ·Isolated design,safe and reliable ·Protections: Short circuit, Over load, over current ·Protection grades is as high as IP65 ·5 years warranty Technical Parameters Model PEE35-1W24V Input Efficiency ≥87%@230VAC, Full load Voltage 120VAC-277VAC Frequency 50/60Hz Current 0.9Amax@120VAC No load power <0.5W PF ≥0.5@120VAC, full load Inrush Current Cold start,29A@230VAC 20us Turn On Del...

detail
